Mine Blasting Vibration Meter

Mine Blasting Vibration Meter
Mine Blasting Vibration Meter
Send Inquiry
Product Code : OnyxMB1
Product Description

Owing to our rich industrial expertise and skills, we are renowned as one of the most profound manufacturers and suppliers of Mine Blasting Vibration Meter. These meters are designed by the adroit professionals by using high quality raw materials. Our offer range of Mine Blasting Vibration Meter is available in different shape and sizes as per the clients specifications. These meters are known for their optimum working speed, longer working life and user-friendly design. We provide these meters to various industries at cost effective prices.


Number of channels

4/7

Sample rate

2048 SPS

Analog to Digital Converter

16 bits

Frequency range (depending on the choosing configuration)

1-315 Hz, 2-250 Hz

Record time

1, 2, 4, 8, 16, 32 s

Trigger mode

Automatic (see note 1), Manual, External

Ports for data transfer

Ethernet (LAN) USB (External disk) GSM/GPRS

Record and data transfer modes

Internal disk, Printer, SMS messages, WEB server FTP server e-mail

Data storage memory

200 MB (see note 2)

External power supply

12 V

Intenal power supply

Li-Ion rechargeable battery

Autonomy

20 hours of continuous use

Visualization

Graphic LCD screen 128x64 pixels

Keyboard

8 keys

Dimensions

180x220x70 mm

Weight (without accesories)

1,9 kg

Operating temperature

-10 ºC to 50 ºC

Storage temperature

-20 ºC to 60 ºC

Operating and storing humidity

Without condensation

2-250 Hz version

Seismic channels measurement range

± 200 mm/s

Resolution

0,01 mm/s

Minimum measurement

0,05 mm/s

Correction response

IIR digital filter

Transducer type

Geophone fn=8 Hz

1-315 Hz version

Seismic channels measurement range

± 120 mm/s

Resolution

0,01 mm/s

Minimum measurement

0,05 mm/s

Correction response

IIR digital filter

Transducer type

Geophone fn=4,5 Hz

Sound channel

Measurement range

± 502 Pa (148 dB)

Resolution

0,1 Pa

Minimum measurement

2 Pa (100 dB)

Frequency response

2-250 Hz, 1-315 Hz

Transducer type

Pressure sensor
